JAKA Zu S ® Collaborative Robots
Meet the JAKA Zu S cobots: advanced perception, natural human-robot
interaction and guaranteed safety, thanks to an integrated force sensor.
JAKA Zu s Cobots Family
Compact and light, the JAKA Zu S series feature several innovations that prioritize safety and precision. Each unit is fitted with an industrial force sensor, which may be installed either at the base or the end of the cobot arm. Integrated with a force control algorithm, the sensor provides a number of benefits.
First, it enables three control modes: constant force, normal tracking, and speed mode. Second, it allows the cobot to ‘feel’ the objects and environment it comes into contact with.
By monitoring external force, it makes sure to never exceed the security value set by the operator, ensuring the safety of both humans, and the objects it is working with. Third, it dynamically communicates with the JAKA app, displaying in real-time all force values, and force control settings.
Altogether, this makes the JAKA Zu s cobots perfectly suited for polishing, sanding or grinding complex surfaces, as well as PCB assembly, palletizing and more.
What Make JAKA Zu s Great for Industrial Automation
Innovative breakthroughs from drag programming to wireless connection continuously led the trend of robotics development.
Integrated Force Sensor
Each JAKA Zu s cobot is fitted with an industrial force sensor, which may be installed either at the base or the end of the cobot arm.
Force Control
Three control modes: constant force, normal tracking, and speed mode allow the cobot to ‘feel’ the objects and environment it comes into contact with. It is easy to adjust force control settings via JAKA App and users see force value in real.
Remote Monitoring
Monitor cobot’s tasks and set alerts with unique security authentication system.
Graphic Programming
On any graphical device – PC, tablet or phone – easily program cobots
and make adjustments, with no prior programming experience necessary.
Drag Teaching
Once the cobot is mounted, easily drag it to any position desired, and it will remember, and save it in a sequence of positions and movements.
No Teach Pendant
JAKA APP is available on tablets, smartphones and PCs. Teach your cobot easily.
Wireless Connection
No annoying wires attached! Enjoy clean and safe space with JAKA cobots.
JAKA Zu S Model Variants
JAKA Zu 3s
Payload 3 kg I Reach 626 mm
JAKA Zu 7s
Payload 7 kg I Reach 819 mm
JAKA Zu 18s
Payload 18 kg I Reach 1073 mm
JAKA Zu 12s
Payload 7 kg I Reach 819 mm
JAKA Zu 5s
Payload 5 kg I Reach 954 mm
Features
Force Sensor
The industrial force sensor, which may be installed at the base or the end
of any Zu s series cobot, increases precision. It gives the cobots an
ability to accurately performs tasks like palletizing, polishing, or
sanding on complex surfaces.
Force Control Module
The force control module, which users may interact with using the JAKA
app, shows force values, and creates a full-arm collision detection
capability. If any external force exceeds the designated security value,
the cobot ceases to apply more force immediately. There are three control modes available: constant force, normal tracking, and speed mode.
Flexibility
- The JAKA cobots have an MTBF of50,000 hours, they can be safely left to operate without maintenance.
- The cobots can be installed at any angle.
- Safety fences are no longer necessary. JAKA cobots react safely to the touch of human workers, other robots and environmental objects.
- Drag teaching and visual programming ensures that cobot integration or reconfiguration time is short.
